Local servers

How a tool call reaches an MCP server that runs on an enrolled machine, and what each route answers.

Some MCP servers work only on the machine that runs the agent, such as a server that reads local files, or a registry package that starts as a local command. A steering repo can pin such a server to machines. Oxagen then sends each call to one of those machines, which runs it and sends the answer back.

The machine starts every exchange. Oxagen opens no connection to it, so the machine needs no open port and no inbound firewall rule.

How a call reaches the machine

The agent calls a tool on a local server through Oxagen's MCP endpoint.
Oxagen checks that the machine is not suspended and is in a group the server's source.machines names. It then signs a call envelope for that machine and holds it.
The machine's collector is already waiting on GET /v1/local-servers/next. It receives the envelope, checks the signature, and runs the call on the local server.
The machine posts the result to POST /v1/local-servers/replies, and Oxagen hands it to the agent.

A machine counts as connected while it polls, and for 10 seconds after its last poll ends. A call to a machine that is not connected fails at once as disconnected. Oxagen keeps no queue for an offline machine, so no call runs later on a machine that was away.

The machine loop

tacho enroll stores a gateway key for the machine, and the collector daemon starts the loop. The loop runs while all three of these hold:

The machine's host.json holds a gateway key.
The machine's enrollment is not revoked.
The machine is not suspended.

When one stops holding, the loop stops. A revoke or a suspension reaches the daemon from Oxagen, and the loop stops then. tacho unenroll stops the daemon, and the loop with it.

The loop pulls from the MCP origin with the gateway key. It never uses a personal API key.

The two routes

Both routes take the gateway key as Authorization: Bearer <key>, and the machine's enrollment id in the X-Tacho-Host header. The header must name the enrollment the key belongs to.

Route	Answers
`GET /v1/local-servers/next`	`200` with one call envelope, or `204` when no call came within 25 seconds
`POST /v1/local-servers/replies`	`204` when a call waits for the reply

The poll holds for up to 25 seconds, and then the machine polls again. When the machine hangs up after Oxagen picked a call for it, Oxagen keeps the call for the machine's next poll.

A deploy of Oxagen's MCP service fails a call in flight at that moment. The machine's next poll reaches the new service, and the agent can call again.

Tool changes

Oxagen checks a local server's tools the way it checks a cloud server's. A discovery waits until a machine in one of the server's source.machines groups polls. That machine lists the server's tools, and a change opens a sync steering PR.

A server can also say its tools changed. When it sends notifications/tools/list_changed during a call, the machine's reply to that call says so. Oxagen then discovers the server again through that machine, unless the server's sync.schedule is manual.

Refusals

Status	Code	When
`401`	`unauthorized`	The key is missing, malformed, invalid, expired, locked to another purpose, or in an archived workspace.
`403`	`forbidden`	The key is not a machine's gateway key, the header names another machine, the machine is unknown, its enrollment expired, or the organization requires single sign-on for the key's creator.
`403`	`forbidden`, reason `host_revoked`	The machine's enrollment is revoked.
`403`	`forbidden`, reason `host_suspended`	The machine is suspended.
`400`	`bad_request`, reason `invalid`	The reply does not match the reply shape.
`409`	`conflict`	No call waits for this reply. The reason says why: `unknown_id` when the call timed out, was answered, or was never sent to this machine, `wrong_machine` when the reply names another machine, and `wrong_kind` when the reply does not answer the call it names.
`405`	`method_not_allowed`	The poll was not a `GET`, or the reply was not a `POST`.

A revoked or suspended machine gets no calls. Enroll it again, or ask an admin to lift the suspension.

The agent reads a refused call as a tool error with a code. A call to a suspended machine fails with machine_suspended before Oxagen signs it. A call to a machine outside the server's groups fails with not_in_group.
